Yale VTE-U VTEF-U Electric Travel Trolley 3000Kg

Yale VTE-U VTEF-U Electric Travel Trolley 3000Kg

by Yale
SKU N06409703-A-3m

Capacity: up to 3000Kg

€2,538.52

Specially recommended for loads over 1000 kg, for transporting over long distances and/or when used frequently.

Suitable for almost all hoists with suspension hook due to universal shackle connection.

Travel motor with worm gear transmission ensures smooth start and self braking – a separate motor brake is not required.

This product can lift a maximum of: 3000Kg

If you require a different maximum lift capacity, please select from the options below:

Availability: Translation missing: en.general.icons.icon_check_circle icon Typically shipped within 3-5 working days

If the options here don't meet your requirements, we can customise your order.

Please give us a call on (021) 4885 311 or complete the quote request form.

Features

  • Standard operating voltage: Euro-voltage 400 V, 3-phase, 50Hz. Single speed motors can be reconnected to 230 V, 3-phase, 50Hz.
  • Motor protected to IP55 against dust and water jets. Push-button pendant control IP 65.
  • Compact, robust frame with low overall height.
  • Wheels manufactured from fracture-proof steel. Smooth running due to machined surfaces and ball bearing mounting. Cambered profile suitable for flat and inclined beam profiles.
  • Anti-drop and anti-tilt devices as standard.
  • Easy adjusted to fit to a wide range of beam widths and profiles due to threaded spindles

Options

  • Low voltage control (42 V)
  • Rubber buffers
  • 230V, 1-phase, 50 Hz
